MODEL |
FDE 315 |
|
|
Pipe Size(mm) |
110, 125, 140, 160, 180, 200, 225, 250, 280, 315 |
|
|
Heating Plate Max. Temp. |
270℃ |
|
|
Temp. deviation |
±5℃ |
|
|
Pressure adjustable Ranges |
0-13Mpa |
|
|
Voltage |
～220V |
|
|
Power frequency |
50Hz |
|
|
Heating plate power |
2.2KW |
|
|
Planing toolr Power |
1.0KW |
|
|
Hydraulic unit power |
0.75KW |
|
|
Total power |
3.95KW |
|
|
Weight |
190kgs |
|
|
Packing Dimension (cm*cm*cm) |
Basic frame |
148*91*105 |
|
Hydraulic Unit |
74*49*62 |
|
|
Control box |
86*100*123 |
|
