MODEL |
FDC630 |
|
|
Pipe Size(mm) |
400,450,500,560,630 |
|
|
Heating Plate Max. Temp. |
270℃ |
|
|
Temp. deviation |
±5℃ |
|
|
Pressure adjustable Ranges |
0-10Mpa |
|
|
Voltage |
～380V |
|
|
Power frequency |
50Hz |
|
|
Heating plate power |
12.2KW |
|
|
Diameter Heating plate |
660mm |
|
|
Thickness Heating plate(mm) |
27mm |
|
|
Planing tool Power |
1.5KW |
|
|
Hydraulic unit power |
1.5KW |
|
|
Total power |
15.2KW |
|
|
Weight |
660KGS |
|
|
Packing Size (cm*cm*cm) |
Basic frame |
140*95*95 |
|
Support |
100*60*127 |
|
|
Hydraulic Unit |
71*49*47 |
|
