MODEL |
FDC 315 |
|
|
Pipe Size(mm) |
160,180,200,225,250,280,315 |
|
|
Heating Plate Max. Temp. |
270℃ |
|
|
Temp. deviation |
±5℃ |
|
|
Pressure adjustable Ranges |
0-10Mpa |
|
|
Voltage |
～220V |
|
|
Power frequency |
50Hz |
|
|
Heating plate power |
3.1KW |
|
|
Diameter Heating plate |
345mm |
|
|
Thickness Heating plate |
24mm |
|
|
Planing tools Power |
1.5KW |
|
|
Hydraulic unit power |
0.75KW |
|
|
Total power |
5.35KW |
|
|
Weight |
220KGS |
|
|
Packing Dimension (cm*cm*cm) |
Basic frame |
74*81*71 |
|
Others |
100*62*62 |
|
