Type |
FDC 160 |
|
|
Materials |
PE，PP，PVDF |
|
|
Max. range of diameter |
160mm |
|
|
Ambient temp. |
－5～45℃ |
|
|
Power supply |
～220V±10％， 50Hz(60Hz) |
|
|
Total power |
2.95Kw |
|
|
Include： Heating plate |
1.2Kw |
|
|
Planing tool |
1.0Kw |
|
|
Hydraulic unit |
0.75Kw |
|
|
IP Grade |
IP54 |
|
|
Dielectric resistance |
>1MΩ |
|
|
Max. pressure |
6.3Mpa |
|
|
Total section of cylinders |
12.56cm2 |
|
|
Max Temperature of heating plate |
270℃ |
|
|
Difference temperature of heating plate interface |
±5℃ |
|
|
Basic frame |
Size，mm |
950×520×500 |
|
Hydraulic unit |
Size，mm |
710×490×470 |
|
Total weight，Kg |
155 |
|
